BB205CCBS Brushed Stainless Double Keyed Cylinders AMR205CCBS Series

The BB Hardware American Style Patch Lock can be mounted on the top or bottom of doors. It can also be used on the vertical edge of the door, and secured to a jamb with the Keeper that is supplied with the unit. The Patch Lock can also be secured to a glass panel or door using the BB206 Sidelite Mount Keeper. A variety of optional keepers, such as BB207 and BB208 are available to accommodate most types of installations.

High Density Cast Body with Lock Mechanism

Gaskets for use with 3/8" or 1/2" (10 or 12 mm) Glass

Bolt Length: 11/16" (17.5 mm)

Optional Cylinders include either BB205CC Double Keyed Cylinders or BB205CT Single Keyed Cylinder with Thumbturn.

GLASS FABRICATION REQUIRED:

Top or Bottom Mount: One 3/4" (19 mm) Diameter Hole and One Corner Notch

Side Mount: One 3/4" (19 mm) Diameter Hole and One U-Cutout (Hole on Top)

COMES WITH:

Template and Instructions

DOES NOT INCLUDE:

Double Keyed Cylinders; Keyed Cylinder/Thumbturn; Optional Keepers (Must Be Ordered Separately)

DOUBLE DOOR APPLICATION:

For double door installations a Bottom Patch Lock is required on the inactive leaf to properly secure the pair of doors.

CRL AMR205CCBS Series
