Brushed Stainless Colcom Full Back Plate Wall-to-Glass Hinge - Non Hold Open 8010BTSFBS 8010BTSF05

flash sale price is limited to quantity on hand

For Self-Closing Glass Doors from 5/16" to 9/16" (8 to 13.52 mm)

Designed for Use on Interior Doors in Humid Conditions and High Temperatures

Adjustable Closing Speed

A Great Alternative to Floor Closers and Patch Fittings

This Full Back Plate Wall Mount Hinge swings in and out a full 90 degrees, with stops at 0, +90, and –90 degrees. Closing speed can be adjusted, making it a great alternative to floor closers and patch fittings. For doors up to 39" (1 m) wide. Maximum weight per two hinges is 220 lbs. (100 kg). Designed for use on interior doors in damp and humid environments and high temperatures, such as steam rooms, Turkish baths and shower doors.

This Hinge represents the evolution and the synthesis between automatic mechanical hinges and hydraulic door closers. Allows you to design a self-closing door without the need of a floor-mounted or overhead closing device. This gives you the advantage of being able to install an 'all-glass' door in an existing opening without the need for extensive retrofitting of hardware into the floor or overhead.

Properly mounted, two  Hinges will support a 5/16" to 9/16" (8 to 13.52 mm) thick glass door up to 39" (1 m) in width and weighing up to 220 lbs. (100 kg). A control valve lets you adjust the hinge to the desired closing speed. And Oil Dynamic is ambidextrous, with positive stops at 0 and 90 degrees, giving you even more design freedom.

This Hinge features an aluminum body in distinct configurations for Wall Mount and Glass-to-Glass applications. These Hinges have been subject to strict testing (over 1 million cycles), assuring long lasting service.

SPECIFICATIONS:

Glass Thickness Range: 5/16" to 9/16" (8 to 13.52 mm)

Construction: Aluminum

Hinge Swings: 90 Degrees Inwards and Outwards (Except H8060 Model, Which Only Swings One Way)

Closing Type: Automatic Closing From 0 to 80 Degrees

Cut-Out Required

Includes: Snap-In Molded Gaskets for 5/16" to 9/16" (8 to 13.52 mm) Glass; Hex Screws Maximum Capacities Using Two Hinges: Door Width: 39" (1 m); Door Weight: 220 lbs. (100 kg)

NOTE: Do not use more than two hinges on one door. Not suitable for exterior and outdoor use. For exterior and outdoor use we recommend H8015JC Series.

Product Warning:

Do not use more than two hinges on one door.

The hinge cover plate uses a 4mm allen key.
